5 inch swivel caster with brake brake fro rack Dajin caster
Lead Time:
20-25days
OEM Availability:
Yes
MOQ:
500 pcs
Payment:
L/C, T/T
Place of Origin:
China
Brand:
PLEYMA
Application Scope
The castor wheels of Dajin caster is applicable to the following areas.In addition to providing high-quality products, Dajin caster also provides effective solutions based on the actual conditions and the needs of different customers.
1. The production of Dajin caster threaded swivel casters is adjusted to meet the needs of customers.
2. The product is unaffected by the frequency of switching on/off, performing stably under rapid cycling. It features a long lifespan after frequent use.
3. The product has a smooth surface that requires little cleaning because the wood materials used are not easy to build up the molds and molds and bacteria.
4. By implementing the policy of threaded swivel casters , Dajin caster has successfully established the rules to improve the production level.
5. Dajin caster is a company, dedicated to the design, develop and production of 5 inch swivel caster with brake .
| Model | Type | Wheel diameter(mm) | Tread width(mm) | Wheel material | Mounting type | Overall height(mm) | Plate size(mm) | Hole spacing(mm) | Threaded stem size(mm) | Load capacity(kgs) |
| 30Z10PUG1-075 | Rigid | 75 | 32 | PU | Plate | 107 | 92*65 | 75*45 | / | 90 |
| 30Z20PUG1-075 | Swivel | 75 | 32 | PU | Plate | 107 | 92*65 | 75*45 | / | 90 |
| 30Z24PUG1-075 | Swivel with brake | 75 | 32 | PU | Plate | 107 | 92*65 | 75*45 | / | 90 |
| 30Z30PUG1-075 | Swivel | 75 | 32 | PU | Threaded stem | 107 | / | / | M12*30 | 90 |
| 30Z34PUG1-075 | Swivel with brake | 75 | 32 | PU | Threaded stem | 107 | / | / | M12*30 | 90 |
| 30Z10PTG1-075 | Rigid | 75 | 32 | TPR | Plate | 107 | 92*65 | 75*45 | / | 70 |
| 30Z20PTG1-075 | Swivel | 75 | 32 | TPR | Plate | 107 | 92*65 | 75*45 | / | 70 |
| 30Z24PTG1-075 | Swivel with brake | 75 | 32 | TPR | Plate | 107 | 92*65 | 75*45 | / | 70 |
| 30Z30PTG1-075 | Swivel | 75 | 32 | TPR | Threaded stem | 107 | / | / | M12*30 | 70 |
| 30Z34PTG1-075 | Swivel with brake | 75 | 32 | TPR | Threaded stem | 107 | / | / | M12*30 | 70 |
| 30Z10PUG1-100 | Rigid | 100 | 32 | PU | Plate | 129 | 92*65 | 75*45 | / | 110 |
| 30Z20PUG1-100 | Swivel | 100 | 32 | PU | Plate | 129 | 92*65 | 75*45 | / | 110 |
| 30Z24PUG1-100 | Swivel with brake | 100 | 32 | PU | Plate | 129 | 92*65 | 75*45 | / | 110 |
| 30Z30PUG1-100 | Swivel | 100 | 32 | PU | Threaded stem | 129 | / | / | M12*30 | 110 |
| 30Z34PUG1-100 | Swivel with brake | 100 | 32 | PU | Threaded stem | 129 | / | / | M12*30 | 110 |
| 30Z10PTG1-100 | Rigid | 100 | 32 | TPR | Plate | 129 | 92*65 | 75*45 | / | 90 |
| 30Z20PTG1-100 | Swivel | 100 | 32 | TPR | Plate | 129 | 92*65 | 75*45 | / | 90 |
| 30Z24PTG1-100 | Swivel with brake | 100 | 32 | TPR | Plate | 129 | 92*65 | 75*45 | / | 90 |
| 30Z30PTG1-100 | Swivel | 100 | 32 | TPR | Threaded stem | 129 | / | / | M12*30 | 90 |
| 30Z34PTG1-100 | Swivel with brake | 100 | 32 | TPR | Threaded stem | 129 | / | / | M12*30 | 90 |
| 30Z10PUG1-125 | Rigid | 125 | 32 | PU | Plate | 155 | 92*65 | 75*45 | / | 130 |
| 30Z20PUG1-125 | Swivel | 125 | 32 | PU | Plate | 155 | 92*65 | 75*45 | / | 130 |
| 30Z24PUG1-125 | Swivel with brake | 125 | 32 | PU | Plate | 155 | 92*65 | 75*45 | / | 130 |
| 30Z30PUG1-125 | Swivel | 125 | 32 | PU | Threaded stem | 155 | / | / | M12*30 | 130 |
| 30Z34PUG1-125 | Swivel with brake | 125 | 32 | PU | Threaded stem | 155 | / | / | M12*30 | 130 |
| 30Z10PTG1-125 | Rigid | 125 | 32 | TPR | Plate | 155 | 92*65 | 75*45 | / | 110 |
| 30Z20PTG1-125 | Swivel | 125 | 32 | TPR | Plate | 155 | 92*65 | 75*45 | / | 110 |
| 30Z24PTG1-125 | Swivel with brake | 125 | 32 | TPR | Plate | 155 | 92*65 | 75*45 | / | 110 |
| 30Z30PTG1-125 | Swivel | 125 | 32 | TPR | Threaded stem | 155 | / | / | M12*30 | 110 |
| 30Z34PTG1-125 | Swivel with brake | 125 | 32 | TPR | Threaded stem | 155 | / | / | M12*30 | 110 |
Product Application
Product Application
❃ Food service carts/Trolleys
❃Bakery racks
❃ Metal brake/Plastic brake available
❃ Single ball bearing or double ball bearing available
Company Features
1. All our 5 inch swivel caster with brake are cutting-edge in this industry.
2. Zhongshan Dajin caster Co.,Ltd. has achieved fruitful technical results thanks to its strong technical foundation.
3. Zhongshan Dajin caster Co.,Ltd.'s aim is to be the first company to break into emerging markets. Inquire now! In order to reduce the impact of our products on the environment, we are devoted to consistent innovation in product design, quality, reliability, and recyclability, so as to be responsible for the environment. Inquire now!
