Professional caster manufacturers - Dajin Caster

Dajin caster medium duty caster wheels carts for dollies 1

Dajin caster medium duty caster wheels carts for dollies 2

Dajin caster medium duty caster wheels carts for dollies 3

Dajin caster medium duty caster wheels carts for dollies 4

Dajin caster medium duty caster wheels carts for dollies 5

Dajin caster medium duty caster wheels carts for dollies

Lead Time:

20-25days

OEM Availability:

Yes

MOQ:

500 pcs

Payment:

L/C, Western Union

Place of Origin:

China

Brand:

PLEYMA

Inquiry

Company Advantages
1. As Dajin caster industrial swivel casters is made of high materials, it meets the international standards. It can be designed to feature 360-degree rotation
2. Except for adopting superior material, medium duty caster wheels is produced on sophisticated equipment. It is ideal for such floors as wood, laminate, ceramic, terracotta or carpeted
3. This product is safe enough. Its fabric contains no toxic substances such as benzene and formaldehyde that would pose risks to health. Brakes are available to improve its usability
4. This product has low chemical emissions. Materials, surface treatments and production techniques with the lowest possible emissions are selected. It is especially suitable for food service trolleys and medical equipment
5. The product features high stitching quality. A measuring tape will be used to simply count the number of stitches per inch on at least two pieces per style to make sure stitch accuracy. Its wheel is less prone to get tangled with hair and debris on the floor

Dajin caster medium duty caster wheels carts for dollies 6

Dajin caster medium duty caster wheels carts for dollies 7

Dajin caster medium duty caster wheels carts for dollies 8

Model	Type	Wheel diameter(mm)	Tread width(mm)	Wheel material	Mounting type	Overall height(mm)	Plate size(mm)	Hole spacing(mm)	Threaded stem size(mm)	Load capacity(kgs)
30Z10PUG1-075	Rigid	75	32	PU	Plate	107	92*65	75*45	/	90
30Z20PUG1-075	Swivel	75	32	PU	Plate	107	92*65	75*45	/	90
30Z24PUG1-075	Swivel with brake	75	32	PU	Plate	107	92*65	75*45	/	90
30Z30PUG1-075	Swivel	75	32	PU	Threaded stem	107	/	/	M12*30	90
30Z34PUG1-075	Swivel with brake	75	32	PU	Threaded stem	107	/	/	M12*30	90
30Z10PTG1-075	Rigid	75	32	TPR	Plate	107	92*65	75*45	/	70
30Z20PTG1-075	Swivel	75	32	TPR	Plate	107	92*65	75*45	/	70
30Z24PTG1-075	Swivel with brake	75	32	TPR	Plate	107	92*65	75*45	/	70
30Z30PTG1-075	Swivel	75	32	TPR	Threaded stem	107	/	/	M12*30	70
30Z34PTG1-075	Swivel with brake	75	32	TPR	Threaded stem	107	/	/	M12*30	70
30Z10PUG1-100	Rigid	100	32	PU	Plate	129	92*65	75*45	/	110
30Z20PUG1-100	Swivel	100	32	PU	Plate	129	92*65	75*45	/	110
30Z24PUG1-100	Swivel with brake	100	32	PU	Plate	129	92*65	75*45	/	110
30Z30PUG1-100	Swivel	100	32	PU	Threaded stem	129	/	/	M12*30	110
30Z34PUG1-100	Swivel with brake	100	32	PU	Threaded stem	129	/	/	M12*30	110
30Z10PTG1-100	Rigid	100	32	TPR	Plate	129	92*65	75*45	/	90
30Z20PTG1-100	Swivel	100	32	TPR	Plate	129	92*65	75*45	/	90
30Z24PTG1-100	Swivel with brake	100	32	TPR	Plate	129	92*65	75*45	/	90
30Z30PTG1-100	Swivel	100	32	TPR	Threaded stem	129	/	/	M12*30	90
30Z34PTG1-100	Swivel with brake	100	32	TPR	Threaded stem	129	/	/	M12*30	90
30Z10PUG1-125	Rigid	125	32	PU	Plate	155	92*65	75*45	/	130
30Z20PUG1-125	Swivel	125	32	PU	Plate	155	92*65	75*45	/	130
30Z24PUG1-125	Swivel with brake	125	32	PU	Plate	155	92*65	75*45	/	130
30Z30PUG1-125	Swivel	125	32	PU	Threaded stem	155	/	/	M12*30	130
30Z34PUG1-125	Swivel with brake	125	32	PU	Threaded stem	155	/	/	M12*30	130
30Z10PTG1-125	Rigid	125	32	TPR	Plate	155	92*65	75*45	/	110
30Z20PTG1-125	Swivel	125	32	TPR	Plate	155	92*65	75*45	/	110
30Z24PTG1-125	Swivel with brake	125	32	TPR	Plate	155	92*65	75*45	/	110
30Z30PTG1-125	Swivel	125	32	TPR	Threaded stem	155	/	/	M12*30	110
30Z34PTG1-125	Swivel with brake	125	32	TPR	Threaded stem	155	/	/	M12*30	110

Product Application

Dajin caster medium duty caster wheels carts for dollies 9

Product Application

❃ Food service carts/Trolleys

❃Bakery racks

❃ Metal brake/Plastic brake available

❃ Single ball bearing or double ball bearing available

Company Features
1. Zhongshan Dajin caster Co.,Ltd. owns a professional team of technicians to keep improving our medium duty caster wheels .
2. Zhongshan Dajin caster Co.,Ltd. will play a role in the development of high quality stem caster wheels . Please contact us!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
