medium furniture swivel casters economic thread for dollies
Lead Time:
20-25days
OEM Availability:
Yes
MOQ:
1000 pcs
Payment:
L/C, T/T, Western Union
Place of Origin:
China
Brand:
PLEYMA
Enterprise Strength
- Dajin caster 's comprehensive service system covers from pre-sales to in-sales and after-sales. It guarantees that we can solve consumers' problems in time and protect their legal right.
Application Scope
With wide application, castor wheels can be used in the following aspects.Dajin caster is able to meet customers' needs to the greatest extent by providing customers with one-stop and high-quality solutions.
1. Quality assessment is assurance for Dajin caster stem swivel caster wheels quality. Its cutting, sewing, dyeing, and other processes, as well as the use of dyes, antibacterial agents and other chemicals, need to pass the relevant tests.
2. This product features the desired stretch strength. It has been checked by using medium force along all its seams, edges, and openings (e.g. an armhole and neckline).
3. The product is available at an affordable price and is currently very popular in the market and is believed to be used more widely in the future.
Product Parameters
| Model | Type | Wheel diameter(mm) | Tread width(mm) | Wheel material | Mounting type | Overall height(mm) | Plate size(mm) | Hole spacing(mm) | Threaded stem size(mm) | Grip ring size(mm) |
| 20Z20PPN1-075 | Swivel | 75 | 27 | PP | Plate | 105 | 92*65 | 75*45 | / | / |
| 20Z22PPN1-075 | Swivel with brake | 75 | 27 | PP | Plate | 105 | 92*65 | 75*45 | / | / |
| 20Z30PPN1-075 | Swivel | 75 | 27 | PP | Threaded stem | 105 | / | / | M12*30 | / |
| 20Z32PPN1-075 | Swivel with brake | 75 | 27 | PP | Threaded stem | 105 | / | / | M12*30 | / |
| 20Z50PPN1-075 | Swivel | 75 | 27 | PP | Grip ring | 105 | / | / | / | M12*60 |
| 20Z52PPN1-075 | Swivel with brake | 75 | 27 | PP | Grip ring | 105 | / | / | / | M12*60 |
| 20Z20PUG0-075 | Swivel | 75 | 27 | PU | Plate | 105 | 92*65 | 75*45 | / | / |
| 20Z22PUG0-075 | Swivel with brake | 75 | 27 | PU | Plate | 105 | 92*65 | 75*45 | / | / |
| 20Z30PUG0-075 | Swivel | 75 | 27 | PU | Threaded stem | 105 | / | / | M12*30 | / |
| 20Z32PUG0-075 | Swivel with brake | 75 | 27 | PU | Threaded stem | 105 | / | / | M12*30 | / |
| 20Z50PUG0-075 | Swivel | 75 | 27 | PU | Grip ring | 105 | / | / | / | M12*60 |
| 20Z52PUG0-075 | Swivel with brake | 75 | 27 | PU | Grip ring | 105 | / | / | / | M12*60 |
| 20Z20PTG0-075 | Swivel | 75 | 27 | TPR | Plate | 105 | 92*65 | 75*45 | / | / |
| 20Z22PTG0-075 | Swivel with brake | 75 | 27 | TPR | Plate | 105 | 92*65 | 75*45 | / | / |
| 20Z30PTG0-075 | Swivel | 75 | 27 | TPR | Threaded stem | 105 | / | / | M12*30 | / |
| 20Z32PTG0-075 | Swivel with brake | 75 | 27 | TPR | Threaded stem | 105 | / | / | M12*30 | / |
| 20Z50PTG0-075 | Swivel | 75 | 27 | TPR | Grip ring | 105 | / | / | / | M12*60 |
| 20Z52PTG0-075 | Swivel with brake | 75 | 27 | TPR | Grip ring | 105 | / | / | / | M12*60 |
| 20Z20PPN1-100 | Swivel | 100 | 27 | PP | Plate | 127 | 92*65 | 75*45 | / | / |
| 20Z22PPN1-100 | Swivel with brake | 100 | 27 | PP | Plate | 127 | 92*65 | 75*45 | / | / |
| 20Z30PPN1-100 | Swivel | 100 | 27 | PP | Threaded stem | 127 | / | / | M12*30 | / |
| 20Z32PPN1-100 | Swivel with brake | 100 | 27 | PP | Threaded stem | 127 | / | / | M12*30 | / |
| 20Z50PPN1-100 | Swivel | 100 | 27 | PP | Grip ring | 127 | / | / | / | M12*60 |
| 20Z52PPN1-100 | Swivel with brake | 100 | 27 | PP | Grip ring | 127 | / | / | / | M12*60 |
| 20Z20PUG0-100 | Swivel | 100 | 27 | PU | Plate | 127 | 92*65 | 75*45 | / | / |
| 20Z22PUG0-100 | Swivel with brake | 100 | 27 | PU | Plate | 127 | 92*65 | 75*45 | / | / |
| 20Z30PUG0-100 | Swivel | 100 | 27 | PU | Threaded stem | 127 | / | / | M12*30 | / |
| 20Z32PUG0-100 | Swivel with brake | 100 | 27 | PU | Threaded stem | 127 | / | / | M12*30 | / |
| 20Z50PUG0-100 | Swivel | 100 | 27 | PU | Grip ring | 127 | / | / | / | M12*60 |
| 20Z52PUG0-100 | Swivel with brake | 100 | 27 | PU | Grip ring | 127 | / | / | / | M12*60 |
| 20Z20PTG0-100 | Swivel | 100 | 27 | TPR | Plate | 127 | 92*65 | 75*45 | / | / |
| 20Z22PTG0-100 | Swivel with brake | 100 | 27 | TPR | Plate | 127 | 92*65 | 75*45 | / | / |
| 20Z30PTG0-100 | Swivel | 100 | 27 | TPR | Threaded stem | 127 | / | / | M12*30 | / |
| 20Z32PTG0-100 | Swivel with brake | 100 | 27 | TPR | Threaded stem | 127 | / | / | M12*30 | / |
| 20Z50PTG0-100 | Swivel | 100 | 27 | TPR | Grip ring | 127 | / | / | / | M12*60 |
| 20Z52PTG0-100 | Swivel with brake | 100 | 27 | TPR | Grip ring | 127 | / | / | / | M12*60 |
| 20Z20PPN1-125 | Swivel | 125 | 27 | PP | Plate | 154 | 92*65 | 75*45 | / | / |
| 20Z22PPN1-125 | Swivel with brake | 125 | 27 | PP | Plate | 154 | 92*65 | 75*45 | / | / |
| 20Z30PPN1-125 | Swivel | 125 | 27 | PP | Threaded stem | 154 | / | / | M12*30 | / |
| 20Z32PPN1-125 | Swivel with brake | 125 | 27 | PP | Threaded stem | 154 | / | / | M12*30 | / |
| 20Z50PPN1-125 | Swivel | 125 | 27 | PP | Grip ring | 154 | / | / | / | M12*60 |
| 20Z52PPN1-125 | Swivel with brake | 125 | 27 | PP | Grip ring | 154 | / | / | / | M12*60 |
| 20Z20PUG0-125 | Swivel | 125 | 27 | PU | Plate | 154 | 92*65 | 75*45 | / | / |
| 20Z22PUG0-125 | Swivel with brake | 125 | 27 | PU | Plate | 154 | 92*65 | 75*45 | / | / |
| 20Z30PUG0-125 | Swivel | 125 | 27 | PU | Threaded stem | 154 | / | / | M12*30 | / |
| 20Z32PUG0-125 | Swivel with brake | 125 | 27 | PU | Threaded stem | 154 | / | / | M12*30 | / |
| 20Z50PUG0-125 | Swivel | 125 | 27 | PU | Grip ring | 154 | / | / | / | M12*60 |
| 20Z52PUG0-125 | Swivel with brake | 125 | 27 | PU | Grip ring | 154 | / | / | / | M12*60 |
| 20Z20PTG0-125 | Swivel | 125 | 27 | TPR | Plate | 154 | 92*65 | 75*45 | / | / |
| 20Z22PTG0-125 | Swivel with brake | 125 | 27 | TPR | Plate | 154 | 92*65 | 75*45 | / | / |
| 20Z30PTG0-125 | Swivel | 125 | 27 | TPR | Threaded stem | 154 | / | / | M12*30 | / |
| 20Z32PTG0-125 | Swivel with brake | 125 | 27 | TPR | Threaded stem | 154 | / | / | M12*30 | / |
| 20Z50PTG0-125 | Swivel | 125 | 27 | TPR | Grip ring | 154 | / | / | / | M12*60 |
| 20Z52PTG0-125 | Swivel with brake | 125 | 27 | TPR | Grip ring | 154 | / | / | / | M12*60 |
Product Application
Product Application
❃ Food service carts
❃Bakery racks
❃ Metal brake/Plastic brake available
Company Features
1. Zhongshan Dajin caster Co.,Ltd. lies in a leading position in the production of furniture swivel casters in China.
2. Zhongshan Dajin caster Co.,Ltd. applies high technology to produce high quality small swivel casters .
3. Guaranteed high-quality 4 inch swivel casters is our commitment. Check now! Zhongshan Dajin caster Co.,Ltd. is a manufacturer with lofty aspirations and good ideals for a worldwide famous medium duty swivel casters provider. Check now! Zhongshan Dajin caster Co.,Ltd. will enhance the reputation of 3 inch swivel casters products. Check now! We plan to become a global small swivel caster wheels exporter. Check now!
